Auto Rubber Tube Cutting Machine
Features:
Cured & Molded Rubber Tube is worn on the Engineering Plastic Shaft for Cutting of Rubber Rings
Advantages:
● X AXIS IS CONTROLLED BY SERVO MOTOR; Y AXIS IS CONTROLLED BY STEPPER MOTOR, HMI Setting for cutting
Width of Rubber Tube, and Easy Operation.
● Easy Setting and Precise Cutting, Increasing Production Capacity.
● Fast Loading and Unloading of Rubber Tube, Automatic Return to Origin after Cutting, and One Operator can operate many machine at the same time
|
MOTOR |
1 KW |
|
POWER SUPPLY |
TO BE CONFIRMED |
|
HMI Control |
Pneumatic, PLC Controlled, & 7” COLOR TOUCH SCREEN |
|
No. of SHAFT |
SINGLE SHAFT, Cutting Knife X 1 SET |
|
Processing range |
RUBBER TUBE APPLICATION: LENGTH 100-250mm, OD ø20 –ø150mm, THICKNESS: 1-10mm ( Remaining Rubber Tube: 30mm) |
|
Spraying |
30-40 PCS/min |
|
Machine size |
(L)1500*(W)700*(H)1700mm |
|
Packing size |
(L)1600*(W)800*(H)1800mm |
|
Machine weight |
N.W.: 400 kg, G.W.: 500kg |
